ET electric truck is intended for freight transportation on the surfaced roads. The truck movement is carried out through pushing of foot throttle driven by impulse control system. To control battery charge level it is applied electronic sensor combined with motormeter. ET electric truck is equipped with all necessary signal lamps, which allow operating the truck on the roads of common use.
Applications:
- industrial companies,
- warehouses,
- railway and river stations, airports.
Characteristics
Specifications | ЕТ2012 | ЕТ2013 | ЕТ3013 |
Rated load capacity, kg | 2000 | 2000 | 3000 |
Movement speed loaded, km/h | 12 | 16 | 16 |
Gradability, % | 12 | 12 | 12 |
Motor power, kW | 3,9 | 5,3 | 6,3 |
Turning radius, mm | 3250 | 3250 | 3250 |
Axel base, mm | 1610 | 1610 | 1610 |
Clierance, mm, max | 110 | 140 | 140 |
Control system | Impulse | Impulse | Impulse |
Battery type | Alkaline/Acid/ Gel |
Acid/ Gel |
Acid/ Gel
Battery capacity, А*h
350/385
210/360/300
280/360/300
Battery voltage, V
48
80
80
Overall lenght, mm
3350
3350
3350
Wigth witout sides, mm
1250
1250
1250
Height without load,mm
1550
1550
1550
Freight platform length, mm
2125
2125
2125
Freight platform heigth, mm
820
835
835
Weight of charged truck, without sides, kg, max
1550
1550
1700
JSC "Sarapulsky Power Generator Plant" belongs to the electrical industry, product specialization - aircraft electrical equipment. The main products of the plant are on-board systems for power generation, control and protection of electrical networks, on-board lighting equipment for aviation.
The quality management system is certified for compliance with the requirements of GOST R ISO 9001.
