ЕТ electric truck without cabin

Contact us for a price
In stock

ET electric truck is intended for freight transportation on the surfaced roads. The truck movement is carried out through pushing of foot throttle driven by impulse control system. To control battery charge level it is applied electronic sensor combined with motormeter.  ET electric truck is equipped with all necessary signal lamps, which allow operating the truck on the roads of common use.



 Applications:

- industrial companies,

- warehouses,

- railway and river stations, airports.

Characteristics

Specifications

ЕТ2012

ЕТ2013

ЕТ3013

Rated load capacity, kg

2000

2000

3000

Movement speed loaded, km/h

12

16

16

Gradability, %

12

12

12

Motor power, kW

3,9

5,3

6,3

Turning radius, mm

3250

3250

3250

Axel base, mm

1610

1610

1610

Clierance, mm, max

110

140

140

Control system

ImpulseImpulse

 Impulse

Battery type

Alkaline/Acid/ Gel

Acid/ Gel


Acid/ Gel

Battery capacity, А*h

350/385

210/360/300

280/360/300

Battery voltage, V

48

80

80

Overall lenght, mm

3350

3350

3350

Wigth witout sides, mm

1250

1250

1250

Height without load,mm

1550

1550

1550

Freight platform length, mm

2125

2125

2125

Freight platform heigth, mm

820

835

835

Weight of charged truck, without sides, kg, max

1550

1550

1700

Made in Udmurtia :
